Product Description
Maintenance and Service Guide 1–13
The external components on the right side of the advanced
docking station are in the following illustration below and
described in Table 1-6.
Right-Side Components, Advanced Docking Station
Table 1-6
Right-Side Components, Advanced Docking Station
Item Component Description
1 Computer eject button
and docking light
Ejects the computer from the docking
station. The docking light is turned on when
the computer is properly aligned.
2 Integrated cable lock slot Supports the cable lock, which secures the
docking station, connected computer, and
MultiBay II drive.
