Product Description
Maintenance and Service Guide 1–15
5 Parallel port Connects a parallel device such as
aprinter.
6 Digital video (DVI) jack Connects a DVI device such as a flat
panel monitor.
7 Power light Is turned on when the docking station
is connected to AC power.
8 RJ-11 (modem) jack Connects a telephone cable.
9 RJ-45 (network) jack Connects a network cable.
10 USB ports (2) Connect USB devices.
11 Smart Adapter power
connector
Connects the docking station to the
HP Smart Adapter AC adapter.
12 External monitor port Connects a VGA monitor.
13 Serial port Connects a serial device such as
a mouse.
14 Keyboard connector Connects a PS/2 keyboard.
15 Audio-in (microphone) jack Connects home audio equipment
such as CD and MP3 players.
16 Composite video jack Connects a composite video device
such as a TV.
17 S-Video-out jack Connects an S-Video device such
as a TV, VCR, or camcorder.
Table 1-7
Rear Components, Docking Station
(Continued)
Item Component Description
