Maintenance and Service Guide A–1
A
Screw Listing
This appendix provides specification and reference information
for the screws used in the HP Docking Station and the
HP Advanced Docking Station.
Phillips M2.5×5.0 Screw Locations
Table A-1
Phillips M2.5×5.0 Screw
Color Qty. Length Thread
Head
Width
Black 3 5.0 mm 2.5 mm 4.0 mm
Where used:
Three screws that secure the cable lock cover to the base enclosure
(documented in Section 5.3)
mm
