B–4 CPQ Manual Title
Connector Pin Assignments
Table B-4
Keyboard/Mouse Connector
Pin Signal Pin Signal
1 Keyboard/mouse DATA 4 +5 VDC
2 Keyboard/mouse DATA 5 Keyboard/mouse CLK
3 Ground 6 Keyboard/mouse CLK
