HP Docking Station - Page 60

Connector Pin Assignments
CPQ Manual Title B–7
Table B-8
Serial Port
Pin Signal Pin Signal
1 Carrier detect 6 Data set ready
2 Receive data 7 Ready to send
3 Transmit data 8 Clear to send
4 Data terminal ready 9 Ring indicator
5Ground
