HP Elite Dragonfly - Page 6

SOP
Document No. : Empire FA Dis-assembly SOP Station :
Operation Des : Ver. : Date :
Fixture list
Qty
Fixture list
Qty
Step：
Attention︰ Pls inform the OP assistant immediately once there is any abnormal
Editor：
Publish：
Zhu Ya IE
Loose Battery screw
3(1/1)
Cross electric low speed screwdriver #0 1
1. Loose screw M2 x 3L (6052B0185401) * 5 。
 Torque value1.5 ± 0.2Kgf．Cm
 The screw cannot be slipped and should not fall into the machine
3
5
1
4
2
2019/8/20
1.00
