Notes : If finding anything uncommon, notice foreman or assistant at once.
Standard Operation Procedure
Document No. : Slice FA Disassembly SOP Station :
Operation name : Ver. : Date :
Holding fixture list (holding fixture standard)
Qty
Holding fixture list (holding fixture standard)
Qty
Step：
Issue Dept.：Auditor：
Stanley Chen
NPSU-PPE
12(1/1)
Disassembly MB
图一
Fig.2
1. Loosen MB
screw(6052B0118301)*1
2. Disassembly MB from middle
frame , and put it in the box .
Push the middle frame of audio
side , and let audio jack been
outside of the middle frame . (Fig.3)
Take the M/B audio side out of the
middle frame , and disassembly
it .(Fig.3)
0.10
2016/6/29
Screw
Push middle frame with finger ,
and let audio jack been outside
of the middle frame.
Fig.3
Cross electrical screwdriver#1 1
Fig.1
Fig.4
To Next Page
