HP ELITE x2 1012 G1 Quickspecs

QuickSpecs
HP Elite x2 1012 G1
Technical Specifications
Not all configuration components are available in all regions/countries.
c04895999 — DA – 15477 — Worldwide — Version 16 – March 22, 2017
Page 18
* Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not available
in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location,
environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.
HP lt4225 LTE/EV-DO Gobi™ 4G Mobile Broadband Module*
Technology/Operating bands
LTE: 1400 (Band 11), 800 (Band 18, Japan 800 lower)
EV-DO: 800 (BC0), 2100 (BC6) MHz
Wireless protocol standards
3GPP Release 8 LTE Specification
EVDO Release 0 and Release A
GPS
Standalone, A-GPS
GPS bands
1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz
Maximum data rates
LTE: 100 Mbps (Download), 50 Mbps (Upload)
CDMA 1x: 153.6 kbps (Download), 153.6 kbps (Upload)
EVDO Rev.A: 3.1 Mbps (Download), 1.8 Mbps (Upload)
Maximum output power
LTE: 23 dBm
CDMA/EVDO: 24dBm
Maximum power consumption
LTE: 1,200 mA (peak); 900 mA (average)
EVDO: 900mA (peak); 720mA (average)
Form Factor
M.2, 3042-S3 Key B
Weight
6 g
Dimensions
(Length x Width x Thickness)
1.65 x 1.18 x 0.09 in (42 x 30 x 2.3 mm)
* Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not
available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due
to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.
HP lt4226 LTE/HSPA+ Gobi 4G Module*
Technology/Operating
bands
LTE: 2100 (Band 1), 800 (Band 19, Japan 800 upper), 1450 (Band 21)
HSPA+: 2100 (Band 1), 800 (Band 6), 800 (Band 19) MHz
Wireless protocol
standards
3GPP Release 8 LTE Specification
WCDMA R99, 3GPP Release 5, 6 and 7 UMTS Specification
GPS
Standalone, A-GPS
GPS bands
1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz
Maximum data rates
LTE: 100 Mbps (Download), 50 Mbps (Upload)
DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload)
HSPA+: 21.6 Mbps (Download), 5.76 Mbps (Upload)
Maximum output power
LTE: 23 dBm
HSPA+: 23.5 dBm
Maximum power
consumption
LTE: 1,200 mA (peak); 900 mA (average)
HSPA+: 1,100 mA (peak); 800 mA (average)
Form Factor
M.2, 3042-S3 Key B
Weight
6 g
Dimensions
(Length x Width x
Thickness)
1.65 x 1.18 x 0.09 in (42 x 30 x 2.3 mm)

HP ELITE x2 1012 G1 Specifications

General

Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2EN
Processor cache	4 MB
Processor cores	2
Processor family	Intel® Core™ m3
Processor series	Intel Core m3-6Y series
Processor socket	BGA 1515
Processor threads	4
Processor codename	Skylake
Processor frequency	0.9 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	20 X 16.5 mm
Conflict-Free processor	Yes
PCI Express slots version	3.0
Processor boost frequency	2.2 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Graphics & IMC lithography	14 nm
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	4.5 W
Maximum number of PCI Express lanes	10
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Internal memory	4 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	180 GB
Display diagonal	12 \
Touch technology	Multi-touch
Display resolution	1920 x 1280 pixels
Graphics card	HD Graphics 515
On-board graphics card ID	0x191E
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	850 MHz
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Country of origin	China
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Battery capacity	2800 mAh
Battery life (max)	10 h
AC adapter power	45 W
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Sustainability certificates	ENERGY STAR
Platform	Windows
Operating system architecture	64-bit
Processor ARK ID	88198
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	213.5 mm
Width	300 mm
Height	8.05 mm
Weight	820 g
