HP ELITE x2 1012 G1 Quickspecs

QuickSpecs
HP Elite x2 1012 G1
Technical Specifications
Not all configuration components are available in all regions/countries.
c04895999 — DA – 15477 — Worldwide — Version 16 – March 22, 2017
Page 32
3ft onto every side, angle and edge onto 2” of plywood over
steel over concrete.
Dust*
The dust test was performed in accordance with MIL-STD-810G,
Method 510.5, Procedure I. Test parameters were set so that the
unit was dusted with Arizona Road Dust for six hours while being
operated. Each cycle was one day (24 hours); ten cycles with the
temperature being cycled between 30°C (86°F) and 60°C (140°F);
and relative humidity was a constant 95%.
Vibration*
The vibration test was performed in accordance with MIL-STD-
810G, Method 514.6, Procedure I category 4. This test evaluated
the units performance after it has been subjected to higher
levels of vibration while in storage: Operational U.S. highway
truck exposure, 1000 mile Simulation and One hour/axis
duration.
Vibration 2*
The vibration test was performed in accordance with MIL-STD-
810G, Method 514.6, Procedure I category 24. This test
evaluated the units performance after it has been subjected to
higher levels of vibration while in storage: Non-operational 0.04
g2/Hz at 20-1000 Hz, -6 dB/octave at 1000-2000 Hz and One
hour/axis duration.
Shock*
The shock test was performed in accordance with IL-STD-810G,
Method 516.6.5, Procedure I. This test objective was to
determine whether the unit could be safely operated after being
exposed to sudden physical shock events while operational. For
this test, 3 shocks were performed across each axis and
direction for a total of 18 shocks -40Gs peak, 11ms.
Freeze/Thaw test*
The Freeze/Thaw test was performed in accordance with MIL-
STD-810G, Method 524.54 Procedure III. The objective of
this test was to determine whether the unit could be safely
operated after being exposed to a temperature drop of -10°C
(14°F) for two hours. Unit is removed and checked for operation.
Sand test*
The Sand test was performed in accordance with MIL-STD-810G,
Method 510.5 Procedure II
Explosive Atmosphere*
The Explosive Atmosphere test was performed in accordance
with MIL-STD 810G, Method 511.5 Procedure I.
*MIL STD 810G testing is not intended to demonstrate fitness for U.S. Department of Defense contract requirements or for
military use. Test results are not a guarantee of future performance under these test conditions. Damage under the MIL STD test
conditions or any accidental damage requires an optional HP Accidental Damage Protection Care Pack.
COUNTRY OF ORIGIN
China

HP ELITE x2 1012 G1 Specifications

General

Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2EN
Processor cache	4 MB
Processor cores	2
Processor family	Intel® Core™ m3
Processor series	Intel Core m3-6Y series
Processor socket	BGA 1515
Processor threads	4
Processor codename	Skylake
Processor frequency	0.9 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	20 X 16.5 mm
Conflict-Free processor	Yes
PCI Express slots version	3.0
Processor boost frequency	2.2 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Graphics & IMC lithography	14 nm
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	4.5 W
Maximum number of PCI Express lanes	10
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Internal memory	4 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	180 GB
Display diagonal	12 \
Touch technology	Multi-touch
Display resolution	1920 x 1280 pixels
Graphics card	HD Graphics 515
On-board graphics card ID	0x191E
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	850 MHz
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Country of origin	China
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Battery capacity	2800 mAh
Battery life (max)	10 h
AC adapter power	45 W
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Sustainability certificates	ENERGY STAR
Platform	Windows
Operating system architecture	64-bit
Processor ARK ID	88198
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	213.5 mm
Width	300 mm
Height	8.05 mm
Weight	820 g
