HP ELITE x2 1012 G1 Quickspecs

QuickSpecs
HP Elite x2 1012 G1
Technical Specifications
Not all configuration components are available in all regions/countries.
c04895999 — DA – 15477 — Worldwide — Version 16 – March 22, 2017
Page 31
Non-operating
-4° to 140° F ( -20° to 60° C )
Battery recharge time
System in OFF or Standby
Mode <3 hours
Fuel Gauge LED
No
Optional travel
battery available
No
MIL-STD 810G TEST
High Temperature test*
The High Temperature test was performed in accordance with
MIL-STD-810G, Method 501.5, Procedure I (Storage). This test
evaluated the units’ performance while it was being exposed to
high temperature conditions: 71°C (160°F) nonoperational. Test
cycle 24 hours; test consisted of seven cycles.
High Temperature test*
The High Temperature test was performed in accordance with
MIL-STD-810G, Method 501.5, Procedure II (Operation). This test
evaluated the units’ performance while it was being exposed to
high temperature conditions: 60°C (140°F) operational. Four
hours duration.
Low Temperature test*
The Low Temperature test was performed in accordance with
MIL-STD-810G, Method 502.5, Procedure I (Storage). This test
evaluated the unit’s performance while it was being exposed to
low temperature conditions: -51°C (-60°F) nonoperational. Four
hours duration.
Low Temperature test*
The Low Temperature test was performed in accordance with
MIL-STD-810G, Method 502.5, Procedure II (Operation). This test
evaluated the unit’s performance while it was being exposed to
low temperature conditions: -29°C (20°F) operational. Four hour
duration.
Thermal Shock test*
The Thermal Shock test was performed in accordance with MIL-
STD-810G, Method 503.5, Procedure I. The objective of this test
was to determine whether the unit could be safely operated
after being exposed to sudden changes in ambient
temperature while non-operational. The high temperature was
set to be 96°C (205°F) and the low temperature to be
-51°C (-60°F); three high-to-low cycles were performed.
Altitude*
The Altitude test was performed in accordance with MIL-STD-
810G, Method 500.5, Procedure I (Storage) and II (Operation).
The altitude level simulated for both procedures was 15,000
feet at 57kPa.Four hour duration.
Humidity*
The humidity test was performed in accordance with MIL-STD-
810G, Method 507.5, Procedure II. Relative humidity 95%.
Temperature cycled between 86oF and 140oF.Test cycle 24
hours; test consisted of ten cycles.
Drop*
The drop test was performed in accordance with MIL-STD-810G,
Method 516.6, Procedure IV. The objective of this test was to
determine whether the unit was operational after being dropped
from desk height. For this test, 26 drops were performed from

HP ELITE x2 1012 G1 Specifications

General

Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2EN
Processor cache	4 MB
Processor cores	2
Processor family	Intel® Core™ m3
Processor series	Intel Core m3-6Y series
Processor socket	BGA 1515
Processor threads	4
Processor codename	Skylake
Processor frequency	0.9 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	20 X 16.5 mm
Conflict-Free processor	Yes
PCI Express slots version	3.0
Processor boost frequency	2.2 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Graphics & IMC lithography	14 nm
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	4.5 W
Maximum number of PCI Express lanes	10
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Internal memory	4 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	180 GB
Display diagonal	12 \
Touch technology	Multi-touch
Display resolution	1920 x 1280 pixels
Graphics card	HD Graphics 515
On-board graphics card ID	0x191E
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	850 MHz
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Country of origin	China
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Battery capacity	2800 mAh
Battery life (max)	10 h
AC adapter power	45 W
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Sustainability certificates	ENERGY STAR
Platform	Windows
Operating system architecture	64-bit
Processor ARK ID	88198
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	213.5 mm
Width	300 mm
Height	8.05 mm
Weight	820 g
