HP ELITE x2 1012 G1 Quickspecs

QuickSpecs
HP Elite x2 1012 G1
Technical Specifications
Not all configuration components are available in all regions/countries.
c04895999 — DA – 15477 — Worldwide — Version 16 – March 22, 2017
Page 30
POWER
HP AC Adapter 45W
USB Type-C™
Dimensions (H x W x D)
66mm x 66mm x 28.5mm
Input
90 to 265 VAC
Input Efficiency
+5V out --78.7% min at 115 VAC/230VAC
+12V out—87.4% min at 115 VAC/230VAC
+15V out –87.73% min at 115 VAC/230VAC
Input frequency range
47 to 63 Hz
Input AC current
1.4 A at 90 VAC and maximum load
Output
Output power
45W
DC output
5V/12V/15V
Hold-up time
5 msec at 115 VAC input
Output current limit
<5A, Over voltage protection
7.85V@5Vout
18V@12Vout
20.5V@15Vout
max automatic shutdown
Connector
USB TYPE C connector
Environmental Design
Operating
temperature
32° to 95° F (0° to 35° C)
Non-operating (storage)
temperature
-4° to 121° F (-20° to 85° C)
Altitude
0 to 16,405 ft (0 to 5,000 m)
Humidity
0% to 95%
Storage Humidity
0% to 95%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency
approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B,
CISPR22 Class B, CCC, NOM-1 NYCE; Reliability - failure rate of less than
0.1% annually within the first three years of operation.
HP 4-cell Polymer Battery (40 WHr )
Dimensions (H x W x L)
Weight
Cells/Type
138.15 x 58.90 x 3.81 mm
5.44 x 2.32 x 0.15 inch
0.166 kg/0.37 lb
4-cell Lithium-Ion
Energy
Watt-hour capacity
Voltage : 7.7V
Amp-hour capactity Ah
Watt-hour capacity : 40 WHr
40 WHr
Temperature
Operating (Charging)
32° to 113° F ( 0° to 45° C)
Operating (Discharging)
14° to 140° F ( -10° to 60° C

HP ELITE x2 1012 G1 Specifications

General

Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2EN
Processor cache	4 MB
Processor cores	2
Processor family	Intel® Core™ m3
Processor series	Intel Core m3-6Y series
Processor socket	BGA 1515
Processor threads	4
Processor codename	Skylake
Processor frequency	0.9 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	20 X 16.5 mm
Conflict-Free processor	Yes
PCI Express slots version	3.0
Processor boost frequency	2.2 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Graphics & IMC lithography	14 nm
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	4.5 W
Maximum number of PCI Express lanes	10
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Internal memory	4 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	180 GB
Display diagonal	12 \
Touch technology	Multi-touch
Display resolution	1920 x 1280 pixels
Graphics card	HD Graphics 515
On-board graphics card ID	0x191E
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	850 MHz
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Country of origin	China
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Battery capacity	2800 mAh
Battery life (max)	10 h
AC adapter power	45 W
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Sustainability certificates	ENERGY STAR
Platform	Windows
Operating system architecture	64-bit
Processor ARK ID	88198
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	213.5 mm
Width	300 mm
Height	8.05 mm
Weight	820 g
