HP ELITE x2 1012 G1 Quickspecs

QuickSpecs
HP Elite x2 1012 G1
Technical Specifications
Not all configuration components are available in all regions/countries.
c04895999 — DA – 15477 — Worldwide — Version 16 – March 22, 2017
Page 27
Environmental
Data
Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
 IT ECO declaration
 US ENERGY STAR®
 EPEAT <Gold> registered in the United States. See http://www.epeat.net
for registration status in your country.
System Configuration
The configuration used for the Energy Consumption and Declared Noise
Emissions data for the Notebook model is based on a “Typically Configured
Notebook”.
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
(Short idle)
6.06 W
6.18 W
6.04 W
Normal Operation (Long
idle)
1.85 W
1.94 W
1.81 W
Sleep
0.39 W
0.42 W
0.37 W
Off
0.27 W
0.3 W
0.26 W
Note:
Energy efficiency data listed is for an ENERGY STAR® compliant product if offered
within the model family. HP computers marked with the ENERGY STAR® Logo are
compliant with the applicable U.S. Environmental Protection Agency (EPA)
ENERGY STAR® specifications for computers. If a model family does not offer
ENERGY STAR® compliant configurations, then energy efficiency data listed is for
a typically configured PC featuring a hard disk drive, a high efficiency power
supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
(Short idle)
21 BTU/hr
21 BTU/hr
21 BTU/hr
Normal Operation (Long
idle)
6 BTU/hr
7 BTU/hr
6 BTU/hr
Sleep
1 BTU/hr
1 BTU/hr
1 BTU/hr
Off
1 BTU/hr
1 BTU/hr
1 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured –
Idle
1.5
8
Fixed Disk – Random
writes
1.8
11
Longevity and
Upgrading
This product can be upgraded, possibly extending its useful life by several years.
Upgradeable features and/or components contained in the product may include:
• 3 USB ports
• 1 PC card slot (type I/II)
• 1 ExpressCard/54 slot
• 1 IEEE 1394 Port

HP ELITE x2 1012 G1 Specifications

General

Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2EN
Processor cache	4 MB
Processor cores	2
Processor family	Intel® Core™ m3
Processor series	Intel Core m3-6Y series
Processor socket	BGA 1515
Processor threads	4
Processor codename	Skylake
Processor frequency	0.9 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	20 X 16.5 mm
Conflict-Free processor	Yes
PCI Express slots version	3.0
Processor boost frequency	2.2 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Graphics & IMC lithography	14 nm
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	4.5 W
Maximum number of PCI Express lanes	10
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Internal memory	4 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	180 GB
Display diagonal	12 \
Touch technology	Multi-touch
Display resolution	1920 x 1280 pixels
Graphics card	HD Graphics 515
On-board graphics card ID	0x191E
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	850 MHz
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Country of origin	China
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Battery capacity	2800 mAh
Battery life (max)	10 h
AC adapter power	45 W
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Sustainability certificates	ENERGY STAR
Platform	Windows
Operating system architecture	64-bit
Processor ARK ID	88198
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	213.5 mm
Width	300 mm
Height	8.05 mm
Weight	820 g
