Left
Component Description
(1)
Power connector Connects an AC adapter
(2)
RJ-45 (network) jack Connects a network cable. The RJ-45 jack has two activity
indicator lights.
●
Amber: The RJ-45 jack is active.
●
Green: The RJ-45 jack is on.
(3) RJ-11 (modem) jack (select models only) Connects a modem cable.
(4) Optical drive Reads and writes (select models only) to an optical disc.
(5) Optical drive light
●
On: The optical drive is being accessed.
●
Off: The optical drive is idle.
(6) Smart card reader Supports optional smart cards.
Left 13
