Bottom
Component Description
(1) Service access cover latch Releases the service access cover so that it can be
removed.
(2) Battery bay Holds the battery.
(3)
Battery release latch Releases the battery from the battery bay.
(4) SIM slot Supports a wireless subscriber identity module (SIM) card.
The SIM card slot is located inside the battery bay.
(5) Drain hole A bottom case drain helps prevent damage caused by
minor accidental spills on the keyboard.
(6) Speakers (2) Produce sound.
(7) Bluetooth compartment Holds the Bluetooth device.
16 Chapter 2 External component identification
