HP EliteBook 2560p Maintenance And Service Guide

Spare part
number
Description
593836-001 Broadcom 4313AGN 802.11a/b/g/n WLAN module
609939-001 AC adapter, 65-W Smart AC adapter with localized cable plug support (3-wire plug with ground pin,
supports 3-pin DC connector)
609948-001 65-W Smart AC adapter with localized cable plug support (3-wire plug with ground pin, supports 3- pin DC
connector) for use in Australia, Bangladesh, Brunei, Cambodia, China, Hong Kong, India, Indonesia, Japan,
South Korea, Laos, Malaysia, Nepal, New Zealand, Pakistan, Philippines, Singapore, Sri Lanka, Taiwan,
Thailand, Vietnam
621565-001 Memory module, 2 GB (PC3-10600, 1333 MHz, DDR3)
621569-001 Memory module, 4 GB (PC3-10600, 1333 MHz, DDR3)
626978-001 Hard drive, 2.50 in, 320 GB, 7200-rpm Self-Encrypting Drive (SED) hard drive (includes bracket)
628824-001 Modem module (56k v.92 MDC data/fax modem)
631252-001 Processor, Intel Dual Core i7-2620M 2.70 GHz processor, (turbo up to 3.40 GHz), 4 MB L3 cache, 4
threads, standard-voltage (35-W)
631253-001 Processor, Intel Dual Core i5-2520M 2.50 GHz processor, (turbo up to 3.20 GHz), 3 MB L3 cache, 4
threads, standard-voltage (35-W)
631255-001 Processor, Intel Dual Core i5-2540M 2.60 GHz processor, (turbo up to 3.30 GHz), 3 MB L3 cache, 4
threads, standard-voltage (35-W)
631954-001 Intel Centrino Advanced N 6205, 2x2 a/b/g/n WiFi Adapter
632155-001 HP hs2340 HSPA+ Mobile Broadband Module
632417-001 Battery, 3 cell, 31 Wh, 2.8 Ah, Li-ion battery
632419-001 Battery, 6 cell, 55 Wh, 2.8 Ah, Li-ion battery
632421-001 Battery, 6 cell, 62 Wh, 2.8 Ah, Li-ion battery
632423-001 Battery, 9 cell, 100 Wh, 3.0 Ah, Li-ion battery
633252-001 750 GB, 7200-rpm 9.50 mm, 6.35 cm (2.50 in) SATA hard drive (includes bracket)
634091-001 8 GB memory module (PC3-10600, 1333 mHz, DDR3)
634400-001 HP un2430 EV-DO/HSPA Mobile Broadband Module
634925-001 500 GB, 7200-rpm 9.50 mm, 6.35 cm (2.50 in) SATA hard drive (includes bracket)
635225-001 250 GB, 7200-rpm 9.50 mm, 6.35 cm (2.50 in) SATA hard drive (includes bracket)
638039-001 Intel Dual Core i5-2410M 2.30 GHz processor, (turbo up to 2.90 GHz), 3 MB L3 cache, 4 threads, standard-
voltage (35-W)
638553-001 31.75 cm (12.50 in) high definition (HD), light-emitting diode (LED), AntiGlare (AG) SVA display panel
641672-001 Hard drive, 320 GB, 7200-rpm 9.50 mm, 6.35 cm (2.50 in) SATA hard drive (includes bracket)
642796-001 Webcam module (select models only), includes microphone and keyboard light
642798-001 Internal microphone module
651358-001 System board for use in all countries and regions except the People's Republic of China and Russia
651359-001 System board for use in only the People's Republic of China and Russia
651360–001 Power button board
30 Chapter 3 Illustrated parts catalog

HP EliteBook 2560p Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	100 C °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-2640M
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	-
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	28
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM67 Express
HDD speed	7200 RPM
HDD interface	SATA II
Storage media	HDD
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	12.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Type	PC
Intel segment tagging	Enterprise
On-board graphics card ID	0x116
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz
Audio system	SRS PS
Pointing device	Touchpad + Pointing Stick
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Networking features	Gigabit Ethernet
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Trial software	Norton Internet Security 2011
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Battery capacity	55 Wh
Battery life (max)	8.5 h
Number of battery cells	6
AC adapter power	65 W
Operating temperature (T-T)	5 - 35 °C
Sustainability certificates	ENERGY STAR
Processor code	SR03R
Processor ARK ID	53464
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Country of origin	China

Weight and Dimensions

Depth	209 mm
Width	305.2 mm
Height	27.4 mm
Weight	1670 g
