3.
If it is necessary to replace the webcam/microphone module:
CAUTION: Handle the webcam/microphone module and microphone module with caution.
These modules have a thin profile and are susceptible to damage when not handled carefully.
a. Remove the webcam/microphone module shield (1) from the webcam/microphone module
and display enclosure. (The webcam/microphone module shield is attached to the webcam/
microphone module and display enclosure with double-sided tape.)
b. Disconnect the webcam/microphone module cable (2) from the webcam/
microphone module.
c.
Remove the webcam/microphone module (3).
The webcam/microphone module is available using spare part number 685413-001. The
microphone module is available using spare part number 694675-001.
4. If it is necessary to replace the display hinges, display hinge covers, and/or display hinge caps:
a.
Remove the display hinge caps (1) from the display hinges.
b.
Remove the two Phillips PM2.0×3.6 screws (2) that secure the display hinge covers to the
display hinges.
Component replacement procedures
99
