Item Component Spare part number
For use in Switzerland 696693-BG1
For use in Taiwan 696693-AB1
For use in Thailand 696693-281
For use in Turkey 696693-141
For use in the United Kingdom and Singapore 696693-031
For use in the United States 696693-001
(3) RTC battery (includes cable and double-sided adhesive) 665733-001
(4) Top cover (includes TouchPad and TouchPad cable):
NOTE: The TouchPad cable is also available in the Cable Kit, spare part number 651384-001.
For use on computer models equipped with a fingerprint reader 685407-001
For use on computer models not equipped with a fingerprint reader 685406-001
Bracket Kit (not illustrated includes top cover left and right brackets) 651381-001
(5) Power button board (includes cable) 685408-001
(6) Smart Card reader assembly (includes Smart Card reader cable and function
LED board cable)
685503-001
(7) Function LED board 685509-001
(8) Fingerprint reader board (includes bracket and cable) 685410-001
(9) Function button board (includes cable) 685409-001
(10) System board (includes replacement thermal material):
For use only on computer models equipped with the Windows 8 Professional
operating system in all countries and regions except the People's Republic of China
and the Ukraine
685404-601
For use only on computer models equipped with the Windows 8 Standard operating
system in all countries and regions except the People's Republic of China and the
Ukraine
685404-501
For use only on computer models equipped with the Windows 7 operating system in
all countries and regions except the People's Republic of China and the Ukraine
685404-001
For use only on computer models equipped with the Windows 7 operating system in
the People's Republic of China and the Ukraine
692857-001
(11) Processor (includes replacement thermal material)
Intel Dual Core i7-3520M 2.90-GHz processor (SC turbo up to 3.60-GHz; 1600-MHz
FSB, 4.0-MB L3 cache, 35 W)
681954-001
Intel Dual Core i5-3360M 2.80-GHz processor (SC turbo up to 3.50-GHz; 1600-MHz
FSB, 3.0-MB L3 cache, 35 W)
681953-001
Intel Dual Core i5-3320M 2.60-GHz processor (SC turbo up to 3.30-GHz; 1600-MHz
FSB, 3.0-MB L3 cache, 35 W)
681952-001
26 Chapter 3 Illustrated parts catalog
