Item Component Spare part number
Intel Dual Core i5-3210M 2.50-GHz processor (SC turbo up to 3.10-GHz; 1600-MHz
FSB, 3.0-MB L3 cache, 35 W)
680645-001
Intel Core i3-3110M 2.40-GHz processor (1600-MHz FSB, 3.0-MB L3 cache, 35 W) 682417-001
(12) Heat sink (includes replacement thermal material) 685508-001
(13) Optical drive (includes bezel and bracket):
DVD±RW Double-Layer with SuperMulti Drive 685502-001
DVD-ROM Drive 685419-001
(14) Base enclosure (includes 4 rubber feet, battery release latch assembly, service cover
release latch assembly, and replacement thermal material)
685403-001
Latch Kit (not illustrated, includes battery release latch assembly components and
service cover release latch assembly components)
685505-001
Rubber Kit (not illustrated, includes base enclosure and display bezel screw covers) 651382-001
(15) Battery (Li-ion):
9-cell, 100-Wh, 3.00-Ah 632423-001
6-cell, 62-Wh, 2.80-Ah 632421-001
6-cell, 55-Wh, 2.80-Ah 632419-001
3-cell, 31-Wh, 2.80-Ah 632417-001
(16) Modem module (56k v.92 MDC data/fax, does not include cable)
NOTE: The modem module does not include a cable. The modem module cable is
included in the Cable Kit, spare part number 651384-001. See
Cable Kit
on page 31 for more Cable Kit information.
628824-001
(17) WWAN module:
HP hs2350 HSPA+ Mobile Broadband Module 710788-001
HP lt2523 LTE/HSPA+ Mobile Broadband Module 710790-001
HP lt2522 LTE/EV-DO Mobile Broadband Module 710789-001
HP un2430 EV-DO/HSPA Mini Card 702080-001
HP un2430 EV-DO/HSPA Mobile Broadband Module 634400-001
(18) WLAN module:
Atheros WB225 1×1 802.11b/g/n Bluetooth Combo Adapter 675794-001
Broadcom 43228 802.11abgn 2×2 Wi-Fi Adapter 669832-001
Intel Centrino Advanced-N 6205 WLAN module 631954-001
(19) Speaker assembly (includes cable) 651377-001
Computer major components
27
