Item Component Spare part number
(20) Bluetooth module (4.0 EDR)
NOTE: The Bluetooth module spare part kit does not include a Bluetooth module
cable. The Bluetooth module cable is included in the Cable Kit, spare part number
693306-001.
655792-001
(21) Memory modules (2, PC3-12800, 1666-MHz, DDR3):
8-GB 670034-001
4-GB 641369-001
2-GB 652972-001
(22) Hard drive (does not include hard drive bracket, hard drive connector adapter, or screws):
750-GB, 7200-rpm, 9.5-mm 633252-001
500-GB, 7200-rpm, 9.5-mm self-encrypting drive 683801-001
500-GB, 7200-rpm, 9.5-mm 634925-001
320-GB, 7200-rpm, 9.5-mm 634862-001
Hard Drive Hardware Kit (not illustrated, includes hard drive bracket, hard drive
connector adapter, and screws)
651380-001
Solid-state drive (not illustrated, does not include bracket, connector, or screws):
256-GB SATA III self-encrypting solid-state drive 697058-001
240-GB SATA III solid-state drive 701657-001
180-GB SATA III solid-state drive 700995-001
160-GB SATA II solid-state drive 697060-001
128-GB SATA III solid-state drive 697057-001
(23) Fan (includes cable) 651378-001
(24) Service cover:
Includes label indicating “Made in China” 685400-001
Includes label indicating country of origin 703148-001
28 Chapter 3 Illustrated parts catalog
