HP EliteBook 2570p User Manual

Spare part number Description
628824-001 Modem module (56k v.92 MDC data/fax, does not include cable)
NOTE: The modem module does not include a cable. The modem module cable is included in the
Cable Kit, spare part number 651384-001. See
Cable Kit on page 31 for more Cable Kit
information.
631954-001 Intel Centrino Advanced-N 6205 WLAN module
632417-001 3-cell, 31-Wh, 2.80-Ah, Li-ion battery
632419-001 6-cell, 55-Wh, 2.80-Ah, Li-ion battery
632421-001 6-cell, 62-Wh, 2.80-Ah, Li-ion battery
632423-001 9-cell, 100-Wh, 3.00-Ah, Li-ion battery
633252-001 750-GB, 7200-rpm, 9.5-mm hard drive (does not include hard drive bracket, hard drive connector
adapter, or screws)
NOTE: The hard drive bracket, hard drive connector adapter, and screws are included in the
Hard Drive Hardware Kit, spare part number 651380-001.
634400-001 HP un2430 EV-DO/HSPA Mobile Broadband Module
634925-001 500-GB, 7200-rpm, 9.5-mm hard drive (does not include hard drive bracket, hard drive connector
adapter, or screws)
NOTE: The hard drive bracket, hard drive connector adapter, and screws are included in the
Hard Drive Hardware Kit, spare part number 651380-001.
641369-001 4-GB memory module (PC3, 12800, 1600-MHz)
651376-001 Plastics Kit (includes ExpressCard slot space saver, optical drive bay space saver, RJ-11 jack plug)
NOTE: See
Plastics Kit on page 33 for more Plastics Kit information.
651377-001 Speaker assembly (includes cable)
651378-001 Fan (includes cable)
651380-001 Hard Drive Hardware Kit (includes hard drive bracket, hard drive connector adapter, and screws)
651381-001 Bracket Kit (includes top cover left and right brackets)
651382-001 Rubber Kit (includes base enclosure rubber bumpers)
651384-001 Cable Kit (includes Bluetooth module cable and modem module cable)
NOTE: See
Cable Kit on page 31 for more Cable Kit information.
652972-001 2-GB memory module (PC3, 12800, 1600-MHz)
655792-001 Bluetooth module 4.0 EDR
NOTE: The Bluetooth module does not include a cable. The Bluetooth module cable is included in
the Cable Kit, spare part number 651384-001. See
Cable Kit on page 31 for more Cable Kit
information.
665733-001 RTC battery (includes cable and double-sided adhesive)
669832-001 Broadcom 43228 802.11abgn 2×2 Wi-Fi Adapter
670034-001 8-GB memory module (PC3, 12800, 1600-MHz)
36 Chapter 3 Illustrated parts catalog

HP EliteBook 2570p Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
LED backlight	Yes
Display diagonal	12.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3210M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	25
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
HDD speed	7200 RPM
HDD interface	SATA II
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Intel segment tagging	Enterprise
Audio system	SRS Pro
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Keyboard layout	-
Pointing device	Touchpad
Operating system installed	Windows 8 Pro
Form factor	Clamshell
Product type	Laptop
Product color	Gray
Country of origin	China
Battery capacity	55 Wh
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR
Processor code	SR0N0
Processor ARK ID	65708
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	209 mm
Width	305 mm
Height	27 mm
Weight	1630 g
