Spare part number Description
675794-001 Atheros WB225 1×1 802.11b/g/n Bluetooth Combo Adapter
680645-001 Intel Dual Core i5-3210M 2.50-GHz processor (SC turbo up to 3.10-GHz; 1600-MHz FSB, 3.0-MB
L3 cache, 35 W; includes replacement thermal material)
681952-001 Intel Dual Core i5-3320M 2.60-GHz processor (SC turbo up to 3.30-GHz; 1600-MHz FSB, 3.0-MB
L3 cache, 35 W; includes replacement thermal material)
681953-001 Intel Dual Core i5-3360M 2.80-GHz processor (SC turbo up to 3.50-GHz; 1600-MHz FSB, 3.0-MB
L3 cache, 35 W; includes replacement thermal material)
681954-001 Intel Dual Core i7-3520M 2.90-GHz processor (SC turbo up to 3.60-GHz; 1600-MHz FSB, 4.0-MB
L3 cache, 35 W; includes replacement thermal material)
682417-001 Intel Core i3-3110M 2.40-GHz processor (1600-MHz FSB, 3.0-MB L3 cache, 35 W; includes
replacement thermal material)
683801-001 500-GB, 7200-rpm, 9.5-mm SED hard drive (does not include hard drive bracket, hard drive
connector adapter, or screws)
NOTE: The hard drive bracket, hard drive connector adapter, and screws are included in the
Hard Drive Hardware Kit, spare part number 651380-001.
685400-001 Service cover (includes label indicating “Made in China”)
685401-001 HP 2570 Docking Station
685403-001 Base enclosure (includes 4 rubber feet, battery release latch assembly, service cover release latch
assembly, and replacement thermal material)
685404-001 System board for use only on computer models equipped with the Windows 7 operating system in
all countries and regions except the People's Republic of China and the Ukraine (includes
replacement thermal material)
685404-501 [a] System board for use only on computer models equipped with the Windows 8 Standard operating
system in all countries and regions except the People's Republic of China and the Ukraine (includes
replacement thermal material)
685404-601 [a] System board for use only on computer models equipped with the Windows 8 Professional
operating system in all countries and regions except the People's Republic of China and the Ukraine
(includes replacement thermal material)
685405-001 Display Hinge Cover Kit (includes left and right display hinge caps, left and right display hinge
covers, and clutch cover)
685406-001 Top cover for use on computer models not equipped with a fingerprint reader (includes TouchPad
and TouchPad cable)
685407-001 Top cover for use on computer models not equipped with fingerprint reader (includes TouchPad and
TouchPad cable)
685408-001 Power button board (includes cable)
685409-001 Function button board (includes cable
685410-001 Fingerprint reader board (includes bracket and cable)
685411-001 Display bezel for use on computer models equipped with a webcam
685412-001 Display bezel for use on computer models not equipped with a webcam
685413-001 Webcam/microphone module
Sequential part number listing
37

HP EliteBook 2570p Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
LED backlight	Yes
Display diagonal	12.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3210M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	25
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
HDD speed	7200 RPM
HDD interface	SATA II
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Intel segment tagging	Enterprise
Audio system	SRS Pro
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Keyboard layout	-
Pointing device	Touchpad
Operating system installed	Windows 8 Pro
Form factor	Clamshell
Product type	Laptop
Product color	Gray
Country of origin	China
Battery capacity	55 Wh
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR
Processor code	SR0N0
Processor ARK ID	65708
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	209 mm
Width	305 mm
Height	27 mm
Weight	1630 g
