3–14 Maintenance and Service Guide
Illustrated parts catalog
501499-001 Plastics Kit
✎
See “Plastics Kit” on page 3-9 for more Plastics Kit spare part information.
501500-001 Cable Kit
✎
See “Cable Kit” on page 3-7 for more Cable Kit information.
501501-001 Base enclosure (includes display release latch and rubber feet)
501502-001 Top cover (includes LED board and cable and display alignment guides)
501503-001 Shield Kit
504169-001 12.1-inch, WXGA LED display assembly (includes ambient light sensor, fingerprint reader, logo, 2
microphones, nameplate, 2 WLAN antenna transceivers and cables, and 2 WWAN antenna
transceivers and cables)
504170-001 12.1-inch, WXGA LED display assembly with webcam (includes ambient light sensor, fingerprint
reader, logo, 2 microphones, nameplate, 2 WLAN antenna transceivers and cables, and 2 WWAN
antenna transceivers and cables)
504171-001 12.1-inch, WXGA LED display assembly with outdoor light (includes ambient light sensor, fingerprint
reader, logo, 2 microphones, nameplate, 2 WLAN antenna transceivers and cables, and 2 WWAN
antenna transceivers and cables)
504172-001 12.1-inch, WXGA LED display assembly with webcam and outdoor light (includes ambient light
sensor, fingerprint reader, logo, 2 microphones, nameplate, 2 WLAN antenna transceivers and
cables, and 2 WWAN antenna transceivers and cables)
504519-001 Hard drive connector cable
506678-001 Intel Wi-Fi Link 5100 802.11a/b/g/n WLAN module for use in Russia, Ukraine, and Pakistan
507056-001 Audio connector board (includes cable)
507057-001 Speaker
509435-001 160-GB, 5400-rpm (include bracket, isolator and connector cable)
510369-001 System board equipped with Intel Core2 Duo SU9300 1.20-GHz processor, 800-MHz FSB, and
3-MB L2 cache (includes thermal replacement material) for use in Russia and the People’s Republic
of China
510370-001 System board equipped with Intel Core2 Duo SL9300 1.60-GHz processor, 1066-MHz FSB, and
6-MB L2 cache (includes thermal replacement material) for use in Russia and the People’s Republic
of China
510371-001 System board equipped with Intel Core2 Duo SL9400 1.86-GHz processor, 1066-MHz FSB, and
6-MB L2 cache (includes thermal replacement material) for use in Russia and the People’s Republic
of China
530589-001 System board equipped with Intel Core2 Duo SL9600 2.13-GHz processor, 800-MHz FSB, and
3-MB L2 cache (includes thermal replacement material) for use in all countries and regions except
for Russia and the People’s Republic of China
530590-001 System board equipped with Intel Core2 Duo SU9400 1.40-GHz processor, 800-MHz FSB, and
3-MB L2 cache (includes thermal replacement material) for use in all countries and regions except
for Russia and the People’s Republic of China
534060-291 6-cell, 4.4-Wh battery
574995-001 1.8-inch, 128-GB solid-state drive (include bracket, isolator and connector cable)
577170-001 65-W AC adapter for use in India
577990-001 250-GB, 5400-rpm (include bracket, isolator and connector cable)
592489-001 Antenna, external
(Continued)
Spare part number Description
