7–8 Maintenance and Service Guide
Screw listing
Phillips PM2.0×4.0 screw
Where used: One screw that secures the Bluetooth module to the base enclosure
Where used:
1 One screw that secures the display converter cable to the system board
2 Two screws that secure the display panel cable to the system board
Color Quantity Length Thread Head diameter
Black 4 4.0 mm 2.0 mm 4.0 mm
