Removal and replacement procedures
Maintenance and Service Guide 4–27
Display assembly
✎
The display assembly spare part kit includes an ambient light sensor, fingerprint reader, logo, 2 microphones,
nameplate, 2 WLAN antenna transceivers and cables, and 2 WWAN antenna transceivers and cables.
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 4-8).
5. Remove the following components:
a. SIM (see “SIM” on page 4-9)
b. Hard drive cover (see “Hard drive” on page 4-10)
c. Keyboard (see “Keyboard” on page 4-17)
d. Hinge cover (see “Hinge cover” on page 4-20)
e. Top cover (see “Top cover” on page 4-21)
Description Spare part number
12.1-inch, WXGA LED display assembly with webcam and outdoor light 504172-001
12.1-inch, WXGA LED display assembly with webcam 504170-001
12.1-inch, WXGA LED display assembly with outdoor light 504171-001
12.1-inch, WXGA LED display assembly 504169-001

HP EliteBook 2730p Specifications

Processor

processor_type	Intel Core 2 Duo Low Voltage Processor
processor_speed	up to 1.86 GHz
L2_cache	6 MB

Memory

memory_type	DDR2 SDRAM
memory_speed	800 MHz
maximum_memory	8192 MB

Internal Storage

hard_drive_capacity	80/120 GB
hard_drive_speed	5400 rpm
solid_state_drive_capacity	80 GB

Display

display_size	12.1 inches
display_resolution	1280 x 800
display_type	WXGA UWVA HP Illumi-Lite LED panel

Power

battery_type	6-cell Lithium-Ion
battery_capacity	44 WHr
power_adapter	65W HP Smart AC Adapter

Weight and Dimensions

height	1.11 in
width	11.42 in
depth	8.35 in
