Screw listing
Maintenance and Service Guide 7–3
Phillips PM2.0×4.0 screw
Where used:
1 Two screws that secure the WLAN module to the system board
2 Two screws that secure the WWAN module to the system board
Where used: 2 screws that secure the modem module to the system board
Color Quantity Length Thread Head diameter
Black 6 4.0 mm 2.0 mm 5.0 mm
