QuickSpecs
HP EliteBook 820 G3 Notebook PC
HP EliteBook 840 G3 Notebook PC
HP EliteBook 850 G3 Notebook PC
Features
Not all configuration components are available in all regions/countries.
c04688005 DA 15295 World Wide Version 1 December 9, 2015
Page 16
Security
Trusted Platform Module (TPM) 1.2 (Infineon SLB9670). Common Criteria EAL4+ Certified.
Upgradable to TPM 2.0. Convertible to FIPS 140-2 Certified mode. (TPM 2.0 is not available for Win 7 32-bit.)
14
HP Fingerprint Reader (On select models)
For more information on HP Client Security Software Suite, refer to http://www.hp.com/go/clientsecurity.
1. Available only on business PCs with HP BIOS.
2. May require a manual recovery step if all copies of BIOS are compromised or deleted
3. For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88.
4. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription.
Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for
availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For
full details visit: http://www.absolute.com/company/legal/agreements/ computrace-agreement. Data Delete is
an optional service provided by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to
use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or
purchase one or more RSA SecurID tokens from Absolute Software.
5. GPS access requires an unobstructed path to multiple satellites. Performance may be affected if/when used
inside of buildings, bridges or heavily congested metropolitan areas. Requires separately purchased GPS
navigation software available from multiple GPS applications.
6. HP Mobile Connect Pro is only available on preconfigured devices with WWAN. For geographic availability refer
to http://www.hp.com/go/mobileconnect
7. Integrated Intel Wi-Di feature is available on select configurations only and requires separately purchased projector, TV or
computer monitor with an integrated or external Wi-Di receiver. External Wi-Di receivers connect to the projector, TV or
computer monitor via a standard HDMI cable, also sold separately.
8. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming media players
that also support Miracast. You can use Miracast to share what you’re doing on your PC and present a slide show. For more
information: http://windows.microsoft.com/en-us/windows-8/project-wireless-screen-miracast
9. Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of
eligible printers, supported documents and image types and other HP ePrint details, see
http://www.hp.com/go/eprintcenter). Requires optional broadband module. Broadband use requires separately
purchased service contract. Check with service provider for coverage and availability in your area. Separately
purchased data plans or usage fees may apply. Print times and connection speeds may vary.
10. Skype is not offered in China.
11. Not preinstalled, however available for download in December 2015 at http://www.hp.com/go/clientmanagement
12. Subscription required.
13. Opt in and internet connection required for updates.
14. This product ships with TPM 1.2 with option to upgrade to TPM 2.0. Upgrade utility is expected to be available
by the end of 2015 via HP Customer Support.
POWER
HP 45W Smart AC Adapter (Not available for Asia, China and India)
HP 45W 2-prong DC jack AC Adapter (Japan only)
HP 65W Smart AC Adapter (Not available for Asia, China and India; for 840 & 850 only)
HP 65W Smart AC Adapter EM (Asia, China and India only)
Power cord is configurable; either 3.2 feet or 6 feet (1.0 or 1.8 meter)
Total length including external AC adapter is 9.2 feet or 12 feet (2.86 or 3.66 meter)

Other manuals for HP EliteBook 820 G3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 820 G3 and is the answer not in the manual?

HP EliteBook 820 G3 Specifications

General IconGeneral
Form factorClamshell
Product typeUltrabook
Product colorSilver
Country of originChina
Bus typeQPI
SteppingD1
Tjunction100 °C
Processor cache3 MB
Processor cores2
Processor modeli5-6200U
System bus rate4 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-6200 series
Processor socketLGA 1356 (Socket B2)
Processor threads4
Processor codenameSkylake
Configurable TDP-up25 W
Processor frequency2.3 GHz
Processor cache typeSmart Cache
Configurable TDP-down7.5 W
Processor lithography14 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency2.8 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x4, 4x1
Thermal Design Power (TDP)15 W
Configurable TDP-up frequency2.4 GHz
Configurable TDP-down frequency0.8 GHz
Maximum number of PCI Express lanes12
Motherboard chipset-
Pointing deviceTouchpad
Spill-resistant keyboardYes
Recovery operating systemWindows 10 Pro
Operating system installedWindows 7 Professional
Processor codeSR2EY
Processor ARK ID88193
Processor package size42 X 24 mm
CPU configuration (max)1
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Memory slots2x SO-DIMM
Internal memory8 GB
Memory clock speed2133 MHz
Internal memory typeDDR4-SDRAM
Maximum internal memory16 GB
Memory layout (slots x size)1 x 8 GB
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
SSD interfaceSATA
Storage mediaSSD
Total storage capacity256 GB
Compatible memory cardsSD, SDHC, SDXC
Display surfaceMatt
Display diagonal12.5 \
Native aspect ratio16:9
On-board graphics card ID1916
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 520
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency300 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)1000 MHz
Battery capacity44 Wh
Battery life (max)- h
Number of battery cells3
AC adapter power45 W
Intel segment taggingEnterprise
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.2
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantity0
Sustainability certificatesENERGY STAR
HP segmentBusiness
HP Software providedHP BIOSphere with HP Sure Start, HP Client Security, HP Image Assistant, HP SoftPaq Download Manager, HP Connection Manager, HP Noise Reduction Software
Harmonized System (HS) code84713000
Weight and Dimensions IconWeight and Dimensions
Depth218.9 mm
Width311 mm
Height18.9 mm
Weight1260 g
