HP EliteBook 820 G3 - Bottom and Front Components; Miscellaneous Parts

QuickSpecs
HP EliteBook 820 G3 Notebook PC
HP EliteBook 840 G3 Notebook PC
HP EliteBook 850 G3 Notebook PC
Features
Not all configuration components are available in all regions/countries.
c04688005 – DA 15295 – World Wide – Version 1 – December 9, 2015
Page 25
15.6" diagonal LED
backlight FHD Slim eDP
SVA (1920 x 1080)
Touch with Camera
Outline Dimensions
(W x H x D)
360.0 x 224.3 x 3.2 mm max
Active Area
344.16 x 193.59 mm
Weight
360 max.
Diagonal Size
15.6”
Surface Treatment
AG/BV
Contrast Ratio
500:1 (typ) - BV, 400:1 (typ) - AG
Touch Enabled
Yes
TSP Type
Capacitive
Refresh Rate
60Hz
Response time
16ms typ.
Pixel Per Inch (PPI)
142
Brightness
300nits
Pixel Resolution
Format
1920 x 1080 (FHD)
Configuration
RGB Stripe
Interface
eDP 1.2 (2 lane)
LCD Mode
TN
Viewing Angle
SVA 45/45/25/35
Note: All display specifications represent the typical specifications provided by HP's component manufacturers; actual
performance may vary either higher or lower.
STORAGE AND DRIVES
500 GB 7200rpm Self
Encrypting Drive (FIPS-
140-2) (Opal 2)
Drive Weight
0.21 lbs (95 g)
Capacity
500 GB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Transfer Rate
Synchronous (maximum)
600 MB/s
Seek Time
(typical reads, including
settling)
Single Track
1.5 ms
Average
12ms
Maximum
18mm-22ms
Cache
32GB
Rotational Speed
7200 rpm
Logical Blocks
976,773,168
Operating Temperature
32° to 140° F (0° to 60° C) [top cover temp]
Features
ATA Security; TCG Opal 2.x, FIPS, S.M.A.R.T., NCQ, Ultra DMA ,
