QuickSpecs
HP EliteBook 820 G3 Notebook PC
HP EliteBook 840 G3 Notebook PC
HP EliteBook 850 G3 Notebook PC
Features
Not all configuration components are available in all regions/countries.
c04688005 DA 15295 World Wide Version 1 December 9, 2015
Page 47
speed.
NIC Device Driver Name
Intel 82579LM/82579V Ethernet Network Connection
Intel® I219-LM Gigabit
Network Connection
Ethernet Features
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-
14)
100 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses
13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses
21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023.
Clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and
100 Mbit/s
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE(Energy Efficient Ethernet)
Jumbo Frame 9K
Auto MDI/MDIX Crossover cable detection
Power
Management
ACPI compliant - multiple power modes
Energy Detect Low Power Mode(Green Ethernet)
Performance
Features
TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload( ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
MACSec Offload (802.3ae)
Intel vPro
iSCSI Boot
Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and
Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet
only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB
(802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status
Interface
PCI Express 1.1 x1 to fully support ASPM L0s/L1 and CLKREQ.
NOTE: Intel 82579 PCIe interface is not PCIe compliant. It operates

Other manuals for HP EliteBook 820 G3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 820 G3 and is the answer not in the manual?

HP EliteBook 820 G3 Specifications

General IconGeneral
Form factorClamshell
Product typeUltrabook
Product colorSilver
Country of originChina
Bus typeQPI
SteppingD1
Tjunction100 °C
Processor cache3 MB
Processor cores2
Processor modeli5-6200U
System bus rate4 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-6200 series
Processor socketLGA 1356 (Socket B2)
Processor threads4
Processor codenameSkylake
Configurable TDP-up25 W
Processor frequency2.3 GHz
Processor cache typeSmart Cache
Configurable TDP-down7.5 W
Processor lithography14 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency2.8 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x4, 4x1
Thermal Design Power (TDP)15 W
Configurable TDP-up frequency2.4 GHz
Configurable TDP-down frequency0.8 GHz
Maximum number of PCI Express lanes12
Motherboard chipset-
Pointing deviceTouchpad
Spill-resistant keyboardYes
Recovery operating systemWindows 10 Pro
Operating system installedWindows 7 Professional
Processor codeSR2EY
Processor ARK ID88193
Processor package size42 X 24 mm
CPU configuration (max)1
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Memory slots2x SO-DIMM
Internal memory8 GB
Memory clock speed2133 MHz
Internal memory typeDDR4-SDRAM
Maximum internal memory16 GB
Memory layout (slots x size)1 x 8 GB
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
SSD interfaceSATA
Storage mediaSSD
Total storage capacity256 GB
Compatible memory cardsSD, SDHC, SDXC
Display surfaceMatt
Display diagonal12.5 \
Native aspect ratio16:9
On-board graphics card ID1916
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 520
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency300 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)1000 MHz
Battery capacity44 Wh
Battery life (max)- h
Number of battery cells3
AC adapter power45 W
Intel segment taggingEnterprise
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.2
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantity0
Sustainability certificatesENERGY STAR
HP segmentBusiness
HP Software providedHP BIOSphere with HP Sure Start, HP Client Security, HP Image Assistant, HP SoftPaq Download Manager, HP Connection Manager, HP Noise Reduction Software
Harmonized System (HS) code84713000
Weight and Dimensions IconWeight and Dimensions
Depth218.9 mm
Width311 mm
Height18.9 mm
Weight1260 g
