QuickSpecs
HP EliteBook 820 G3 Notebook PC
HP EliteBook 840 G3 Notebook PC
HP EliteBook 850 G3 Notebook PC
Features
Not all configuration components are available in all regions/countries.
c04688005 – DA 15295 – World Wide – Version 1 – December 9, 2015
Page 49
POWER
HP 45W Smart
AC Adapter
Dimensions (H x W x D)
3.74 x 1.57 x 1.04 in (9.5 x 4.0 x 2.65 cm)
Weight
0.386 lb (175g) max
Input
90 to 265 VAC
Input Efficiency
87.74% at 115Vac and 88.4% at 230Vac
Input frequency range
47 to 63 Hz
Input AC current
1.4 A at 90 VAC
Output
Output power
45W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<8.0A
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating
temperature
32° to 95° F (0° to 35° C)
Non-operating (storage)
temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety
Certifications
*CE Mark - full compliance with LVD and EMC directives
* Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC
Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
* MTBF - over 200,000 hours at 25°C ambient condition.
HP 65W Smart
AC Adapter EM
Dimensions
4.98 x 1.97 x 1.18 in (12.65 x 5.0 x 3.0 cm)
Weight
0.62 lb (290g) max
Input
90 to 265 VAC
Input Efficiency
87% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 VAC
Output
Output power
65W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<11.0A
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating
temperature
32° to 95° F (0° to 35° C)
Non-operating (storage)
-4° to 185° F (-20° to 85° C)
