Table 3-2 Display component descriptions and part numbers (continued)
Item Component Spare part number
IR camera M08549-001
(3) Display panel
1000 nits, ambient light sensor M08527-001
250 nits, models with WWAN M08536-001
250 nits, models without WWAN, IR camera, Touch-on Panel (TOP) M08539-001
400 nits, models without WWAN, IR camera, ambient light sensor M08540-001
(4) Hinge cover (included in Hinge Kit) M08555-001
(5) Ambient light sensor M07212-001
(6) Hinges (left and right) M08555-001
(7) Second ambient light sensor to display panel cable (included in Cable Kit) M08526-001
(8) Second ambient light sensor to hub board cable (included in Cable Kit) M08526-001
(9) Second ambient light sensor
Nonprivacy models M07213-001
Privacy models with WWAN M08553-001
(10) Microphone module M07208-001
(10) Third microphone module M07209-001
(11) Ambient light sensor board to hub board cable (included in Cable Kit) M08526-001
(12) Ambient light sensor board to display panel cable (included in Cable Kit) M08526-001
(13) Camera cable (included in Cable Kit) M08526-001
(14) Display cable (included in Display Cable Kit) M15627-001
(15) Hub board
For use in models with an RGB camera or microphone module M07210-001
For use in models with an IR camera M07211-001
(16) Display cable (included in Display Cable Kit) M15627-001
(17) WLAN antennas and cables
(18) WWAN antennas and cables
(19) Display back cover
Models with WWAN, 250 nit panel, Touch-on Panel (TOP) M08541-001
Models with WWAN, 400 nit panel M08542-001
Models without WWAN, 250 nit panel, Touch-on Panel (TOP) M08543-001
Models without WWAN, privacy M08544-001
Display assembly subcomponents 21
