HP EliteBook 835 G7 - NFC Module, Fan, and Heat Sink Replacement

5. Remove the touchpad from the computer (5).
Reverse this procedure to install the touchpad.
NFC module
To remove the NFC module, use this procedure and illustration.
Table
6-9 NFC module description and part number
Description Spare part number
NFC module M07214-001
NFC module cable (included in Cable Kit) M08526-001
Before removing the NFC module, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 33).
2. Remove the bottom cover (Bottom cover on page 33).
3. Remove the battery (see Battery on page 43).
Remove the NFC module:
1. Disconnect the system board cable from the ZIF connector on the NFC module (1).
2. Disconnect the touchpad cable from the reverse ZIF connector on the NFC module (2).
52 Chapter 6 Removal and replacement procedures for authorized service provider parts
