Table 3-4 Bracket Kit component descriptions and part numbers
Item Component Spare part number
Bracket Kit, includes: M08556-001
(1) Solid-state drive cover
(2) Memory cover
(3) Fingerprint reader bracket
(4) USB bracket
SIM bracket (not illustrated)
Plastics Kit
To identify the Plastics Kit components, use this illustration and table.
Table 3-5 Plastics Kit component descriptions and part numbers
Item Component Spare part number
Plastics Kit, includes: M07215-001
(1) I/O frame
(2) SIM card insert
(3) WWAN insulator
(4) Smart card reader insert
(5) Fingerprint reader insert
Plastics Kit 23
