Replacing a drive on a Windows 2000 platform
If you are replacing an older drive on a Windows 2000 platform, you may need to update the
registry if you are using an Advanced Format drive as a replacement.
The drives originally installed on Windows 2000 platforms tend to have capacities below 137 GB,
which is typically less than an Advanced Format drive. Thus, if your Advanced Format drive is larger
than 137 GB, you must enable 48-bit logical block addressing (LBA) support in the system registry in
order to make all of your storage available. Perform the following steps:
1. Start the registry editor (regedt32.exe).
2. Browse to and select the following registry key:
HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\Atapi\Parameters
3. From the Edit menu, select Add Value and add the following registry value:
Value name: EnableBigLba
Data type: REG_DWORD
Value data: 0x1
4. Quit the registry editor.
Enhancing performance with many small writes (as with ImageX)
Among the issues addressed by Microsoft Knowledge Base article 982018 is performance
degradation associated with a Windows 7 or WinPE platform performing many small writes to an
Advanced Format drive. For example, using the ImageX command-line tool to apply a Windows
image (.wim file) to an Advanced Format drive would take significantly longer than applying the
same image to a traditional hard drive.
To optimize performance, you should apply
the appropriate hotfix to your HP Business Notebook and
Desktop PCs, as described in Enhancing the performance of small writes
.
Validating partition alignment
This section outlines the following options for validating partition alignment:
• Using the DISKEXT command-line utility (for Windows XP or later platforms)
• Using the Windows Management Information Command-line (WMIC) utility (for Windows XP or
later platforms)
• Using the DISKPART command-line utility (for Windows 7 platforms)
Sample calculations are also provided.
Using DISKEXT
1. After the operating system has been installed, download the DISKEXT utility from
http://technet.microsoft.com/en-us/sysinternals/bb896648
; install.
2. Run diskext from the Windows command line.
3. Identify the Partition Starting Offset value of each partition and divide by 4096. If the value is
divisible, the partition is aligned

HP EliteBook 8460p Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-2410M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-2400 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	23
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM67 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Audio system	SRS Premium Sound
Pointing device	Touchpad
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	3
CardBus PCMCIA slots quantity	0
Cable lock slot type	Kensington
AC adapter power	65 W
Battery capacity	62 Wh
Number of battery cells	6
Storage relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Product color	Black, Silver
Country of origin	China
On-board graphics card ID	0x116
Discrete graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1200 MHz
Processor ARK ID	52224
Processor package size	37.5x37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	231 mm
Width	338 mm
Height	34 mm
Weight	2070 g
