13. If it is necessary to replace the display/webcam cable, lift the display/webcam cable assembly (1) from
the routing path on the side of the display enclosure (2), and then remove the cable (3).
The display cable is available in the Cable Kit using spare part number 914749-001.
14. If it is necessary to replace the WLAN antenna cables, peel the transceivers from the top of the display
enclosure (1), remove the antenna cables from the routing path on the sides of the display enclosure
(2), and then remove the antenna cables (3).
NOTE: The WLAN antennas are spared with the display enclosure.
Component replacement procedures 75
