Note the following when backing up:
Store personal files in the Documents library, and back it up regularly.
Back up templates that are stored in their associated programs.
Save customized settings that appear in a window, toolbar, or menu bar by taking a screen shot
of your settings. The screen shot can be a time-saver if you have to reset your preferences.
To create a screen shot:
1. Display the screen you want to save.
2. Copy the screen image:
To copy only the active window, press alt+fn+prt sc.
To copy the entire screen, press fn+prt sc.
3. Open a word-processing document, and then select Edit > Paste.
The screen image is added to the document.
4. Save the document.
When backing up to discs, use any of the following types of discs (purchased separately): CD-R,
CD-RW, DVD+R, DVD+R DL, DVD-R, DVD-R DL, or DVD±RW. The discs you use will depend
on the type of optical drive installed in your computer.
NOTE: DVDs and DVDs with double-layer (DL) support store more information than CDs, so
using them for backup reduces the number of recovery discs required.
When backing up to discs, number each disc before inserting it into the optical drive of the
computer.
To create a backup using Backup and Restore, follow these steps:
NOTE: Be sure that the computer is connected to AC power before you start the backup process.
NOTE: The backup process may take over an hour, depending on file size and the speed of the
computer.
1. Select Start > All Programs > Maintenance > Backup and Restore.
2. Follow the on-screen instructions to set up your backup, create a system image (select models
only), or create a system repair disc (select models only).
NOTE: Windows includes the User Account Control feature to improve the security of your
computer. You may be prompted for your permission or password for tasks such as installing
software, running utilities, or changing Windows settings. Refer to Windows Help and Support
for more information.
124 Chapter 7 Backup and recovery

Table of Contents

Other manuals for HP EliteBook 8540P

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8540P and is the answer not in the manual?

HP EliteBook 8540P Specifications

General IconGeneral
Bus typeDMI
SteppingK0
Tjunction105 °C
Processor cache4 MB
Processor cores2
Processor modeli7-640M
System bus rate2.5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-600 Mobile Series
Processor socketBGA 1288
Processor threads4
Processor codenameArrandale
Processing Die size81 mm²
Processor frequency2.8 GHz
Processor cache typeSmart Cache
Processor lithography32 nm
Processor manufacturerIntel
PCI Express slots version2.0
Processor boost frequency3.46 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)21
Maximum number of PCI Express lanes16
Number of Processing Die Transistors382 M
Motherboard chipsetIntel® QM57 Express
HDD speed7200 RPM
HDD interfaceSATA
Optical drive type-
Card reader integratedYes
Total storage capacity320 GB
Number of HDDs installed1
Display diagonal15.6 \
Display resolution1600 x 900 pixels
Native aspect ratio16:9
Modem speed56 Kbit/s
Power supply typeAC/DC
Intel segment taggingEnterprise
Compliance industry standardsIEEE802.3, IEEE802.3u, IEEE802.3ab
Internal memory4 GB
Memory clock speed1333 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
On-board graphics card modelIntel® HD Graphics
On-board graphics card base frequency500 MHz
On-board graphics card dynamic frequency (max)766 MHz
Pointing deviceTouchpad
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version2.1+EDR
Cabling technology10/100/1000Base-T(X)
Networking featuresGigabit Ethernet
Operating system installedWindows 7 Professional
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity0
AC adapter power90 W
Battery capacity73 Wh
Number of battery cells8
Product colorBlack, Silver
Country of originChina
Processor codeSLBTN
Processor ARK ID49666
Processor package sizerPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography45 nm
Supported instruction setsSSE4.1/4.2
Intel® Turbo Boost Technology1.0
Physical Address Extension (PAE)36 bit
Weight and Dimensions IconWeight and Dimensions
Depth252 mm
Width374 mm
Height32 mm
Weight2950 g
