Item Description Spare part number

For use in Norway 595790-091

For use in Portugal 595790-131

For use in Russia 595790-251

For use in Saudi Arabia 595790-171

For use in Slovenia 595790-BA1

For use in South Korea 595790-AD1

For use in Spain 595790-071

For use in Sweden 595790-B71

For use in Switzerland 595790-BG1

For use in Taiwan 595790-AB1

For use in Thailand 595790-281

For use in Turkey 595790-141

For use in the United Kingdom 595790-031

For use in the United States 595790-001

(4) Top cover (includes TouchPad button and bracket)

For use with HP EliteBook 8540p computer models that include a fingerprint reader 595775-001

For use with HP EliteBook 8540p computer models that do not include a fingerprint reader 595776-001

For use with HP EliteBook 8540w computer models that include a fingerprint reader 595777-001

For use with HP EliteBook 8540w computer models that do not include a fingerprint reader 595778-001

Fingerprint reader board (not illustrated; includes fingerprint reader board cable) 595780-001

(5) Fan 595769-001

(6) Heat sink (includes replacement thermal material)

For use in computers with NVIDIA Quadro FX 1800 graphics (includes fan) 595766-001

For use in computers with NVIDIA Quadro FX 880 or NVIDIA NVS 5100 graphics (does not

include fan)

595767-001

For use in computers with ATI FirePro M5800 graphics (includes fan) 595768-001

(7) Processor

Intel Core i7 processors, Quad Core

840QM, 1.86-GHz (Turbo up to 3.06) processor 8-MB L3 cache, 8 threads 612260-001

820QM, 1.73-GHz (Turbo up to 3.06) processor 8-MB L3 cache, 8 threads 583053-001

740QM, 1.73-GHz (Turbo up to 2.80) processor 6-MB L3 cache, 8 threads 612259-001

720QM, 1.66-GHz (Turbo up to 2.80) processor 6-MB L3 cache, 8 threads 586170-001

Intel Core i7 processor, Dual Core

640M, 2.80-GHz (Turbo up to 3.46) processor 4-MB L3 cache, 4 threads 625826-001

620M, 2.66-GHz (Turbo up to 3.33) processor 4-MB L3 cache, 4 threads 587259-001

24 Chapter 3 Illustrated parts catalog
