HP EliteBook 8540P Maintenance And Service Guide

Spare part
number
Description
595790-B71 Keyboard with pointing stick for use in Sweden (includes keyboard and pointing stick cables)
595790-BA1 Keyboard with pointing stick for use in Slovenia (includes keyboard and pointing stick cables)
595790-BB1 Keyboard with pointing stick for use in Israel (includes keyboard and pointing stick cables)
595790-BG1 Keyboard with pointing stick for use in Switzerland (includes keyboard and pointing stick cables)
595790-DD1 Keyboard with pointing stick for use in Iceland (includes keyboard and pointing stick cables)
595790-DJ1 Keyboard with pointing stick for use in Greece (includes keyboard and pointing stick cables)
595820-001 NVIDIA NVS 5100 graphics card (includes replacement thermal material)
595821-001 NVIDIA Quadro FX 880 graphics card (includes replacement thermal material)
595822-001 NVIDIA Quadro FX 1800 graphics card (includes replacement thermal material)
595823-001 ATI FirePro M5800 graphics card
600755-001 39.6-cm (15.6-in) LED display assembly, FHD for use in model 8540p computers with a webcam (includes
3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
600756-001 39.6-cm (15.6-in) LED display assembly, HD, AntiGlare for use in model 8540w computers without a
webcam (includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and
cables)
600757-001 39.6-cm (15.6-in) LED display assembly, HD, AntiGlare for use in model 8540w computers with a webcam
(includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
600758-001 39.6-cm (15.6-in) LED display assembly, FHD for use in model 8540w computers without a webcam
(includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
600759-001 39.6-cm (15.6-in) LED display assembly, FHD for use in model 8540w computers with a webcam (includes
3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
600760-001 39.6-cm (15.6-in) LED display assembly, HD+ WVA for use in computers without a webcam (includes
3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
600761-001 39.6-cm (15.6-in) LED display assembly, HD+ WVA for use in computers with a webcam (includes 3 WLAN
antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
603783-001 320-GB, 7200-rpm hard drive (includes hard drive bracket and screws)
606979-001 39.6-cm (15.6-in) LED display assembly, FHD, DreamColor for use in model 8540w computers without a
webcam (includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and
cables)
606980-001 39.6-cm (15.6-in) LED display assembly, FHD, DreamColor for use in model 8540w computers with a
webcam (includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and
cables)
612259-001 Intel Core i7 740QM Quad Core processor, 1.73-GHz (Turbo up to 2.80), 8-MB L3 cache, 8 threads
612260-001 Intel Core i7 840QM Quad Core processor, 1.86-GHz (Turbo up to 3.06), 8-MB L3 cache, 8 threads
613153-001 90-W AC adapter
613154-001 120-W AC adapter
613156-001 150-W AC adapter
613160-001 90-W AC adapter for use in India
615116-001 Display cable for use with DreamColor displays
38 Chapter 3 Illustrated parts catalog

HP EliteBook 8540P Specifications

General

Bus type	DMI
Stepping	K0
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-640M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-600 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	3.46 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	21
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QM57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	-
Card reader integrated	Yes
Total storage capacity	320 GB
Number of HDDs installed	1
Display diagonal	15.6 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Modem speed	56 Kbit/s
Power supply type	AC/DC
Intel segment tagging	Enterprise
Compliance industry standards	IEEE802.3, IEEE802.3u, IEEE802.3ab
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Pointing device	Touchpad
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
AC adapter power	90 W
Battery capacity	73 Wh
Number of battery cells	8
Product color	Black, Silver
Country of origin	China
Processor code	SLBTN
Processor ARK ID	49666
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	252 mm
Width	374 mm
Height	32 mm
Weight	2950 g
