HP EliteBook 8560p Specification

HP ProtectTools Security
Manager with Central
Management
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. The ProtectTools modules are available on the hard drive
(also downloadable from the web) and can be configured in Software Setup.
HP ProtectTools is centrally manageable with the capability to manage notebooks from a single point. HP
ProtectTools is management ready out of the box, in partnership with Digital Persona. Features address
requirements that customers expect from a centrally managed security solution such as user provisioning,
credential reset, and credential revocation.
HP ProtectTools provides two separate management solutions, targeted at the enterprise and the SMB:
Digital Persona Pro AD: Designed for the enterprise customer. Integrates with Active Directory and
gives IT Managers the ability to provision users, create login policies based on passwords,
biometrics or smartcards. Management features also include remote credential recovery in case the
user forgets the password, loses the smartcard or cannot use the fingerprint reader for any reason.
In addition, advanced auditing capabilities are also built in. Digital Persona Pro AD is available now.
Digital Persona Pro Workgroup: Designed for the small business customer. Provides features
similar to the Active Directory version, but for workgroups. Workgroup activation is built into HP
ProtectTools, and activation of up to 5 seats is completely free.
For more information on Central Management for HP ProtectTools, refer to:
http://www.hp.com/products/security .
Power Supply Models with discrete graphics or quad-core processor:
External 90-watt Smart AC adapter
Models with integrated graphics and without quad-core processor:
External 65-watt Smart AC adapter
Power cord included is 6-foot (1.8 meter).
Total length including external AC adapter is 12 feet (3.66 meter).
HP Fast Charge *
*HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP Fast
Charge does not apply to the 9-cell primary battery, HP ST09 Extended Life Notebook Battery, or HP BB09
Ultra Extended Life Notebook Battery.
Battery Primary battery HP 9-cell (100 WHr) Li-Ion battery
HP 6-cell (62 WHr) Li-Ion battery
HP Long Life 6-cell (55 WHr) Li-Ion battery
Secondary battery
Options
HP BB09 Ultra Extended Life Notebook Battery (9-cell 100 WHr)
HP ST09 Extended Life Notebook Battery (9-cell 73 WHr)
QuickSpecs
HP EliteBook 8460p Notebook PC
HP EliteBook 8560p Notebook PC
Standard Features (availability may vary by country)
DA - 13947 North America — Version 20 — August 3, 2012 Page 13

HP EliteBook 8560p Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Display	LED
Expansion slots	1 Express Card/54; 1 lettore di Smart Card; 1 SD/MMC
Infrared data port	No
HDD controller type	Unità a stato solido
Graphics card family	AMD
Intel segment tagging	Enterprise
Bundled software	Roxio My DVD 2010 SE Microsoft Office 2010 Norton Internet Security 2011
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Motherboard chipset	Intel® QM67 Express
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Display diagonal	15.6 \
Display resolution	- pixels
Audio system	SRS HD
Audio included	Audio ad alta definizione SRS, altoparlanti stereo integrati, uscita stereo cuffie/linea, ingresso microfono stereo, microfono integrato (array doppio microfono con webcam opzionale)
Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-2620M
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	27
Maximum number of PCI Express lanes	16
Pointing device	Touchpad + Pointing Stick
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
AC adapter power	65 W
Battery capacity	55 Wh
Number of battery cells	6
Sustainability certificates	ENERGY STAR
On-board graphics card ID	0x116
Discrete graphics card model	AMD Radeon HD 6470M
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz
Processor code	SR041
Processor ARK ID	52231
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Country of origin	China

Weight and Dimensions

Depth	250 mm
Width	374 mm
Height	34 mm
Weight	2730 g
