HP EliteBook 8560p Specification

At A Glance
Genuine Windows 7 versions or FreeDOS
Widescreen LED-backlit display
HP EliteBook 8460p: 14.0-inch diagonal HD or HD+
HP EliteBook 8560p: 15.6-inch diagonal HD, HD+ wide viewing angle, or FHD wide viewing angle
Choice of 2nd generation Intel® Core™ i7 and i5 processors
Intel Core i7 with vPro and Core i5 with vPro technology (optional)
AMD Radeon™ HD 6470M discrete graphics with 1 GB dedicated video memory or integrated Intel® HD Graphics 3000 (Intel HD
Graphics 3000 are available on the 8460p only)
All new design with aluminum display enclosure, magnesium-reinforced chassis, wear-resistant platinum-colored HP
DuraFinish, HP DisplaySafe frame, precision aluminum-alloy hinges, cast titanium-alloy display latches, keyboard in full
aluminum deck, and chemically strengthened glass touchpad; designed to meet the military standard Mil-Std-810G for
vibration, dust, altitude, and high temperature operation *
Easily hot dock with one of the optional HP docking stations
AMD Eyefinity Technology for advanced multi-monitor support
DisplayPort for high resolution support
SRS Premium Sound optimized for high fidelity audio
Choice of primary battery to optimize run-time or weight: 9-cell (100 WHr), 6-cell (62 WHr), or 6-cell (55 WHr) HP Long Life
Battery
Flexible wireless connectivity options:
Optional integrated HP un2430 EV-DO/HSPA Mobile Broadband Module (Gobi 3000) provides GPS functionality
(availability expected May, 2011)
Integrated Intel Centrino® 802.11 a/b/g/n 2x2 or a/b/g/n 3x3, Atheros 802.11 a/b/g/n 3x3, or Broadcom 802.11 a/b/g/n
2x2 or b/g/n 1x1 wireless LAN module
Bluetooth® v2.1+EDR
HP Power Assistant allows you to conserve power, stretch battery run-time, accurately monitor the energy usage of the PC and
up to four select HP external monitors, and report workforce power consumption.
HP QuickWeb for convenient online access without long boot-up times
Upgrade Bay for optical drive, optional second hard drive, or weight saver
Choice of 7200 rpm user-removable hard drive up to 750 GB with HP 3D DriveGuard protection,
or 128/160 GB Solid State Drive
Security features including HP ProtectTools, with central management across HP and non-HP client PCs
BFR/PVC-free ** , ENERGY STAR® qualified, *** and EPEAT Gold registered in the U.S. EPEAT status varies by country-—please see
epeat.net .
* Testing was not intended to demonstrate fitness for DOD contracts requirements or for military use. Test results are not a guarantee
of future performance under these test conditions.
** Meeting the industry definition of 'BFR/PVC-free' per the iNEMI Position Statement on "Low Halogen" Electronics. Plastic parts
incorporated into the chassis generally contain < 1000 ppm (0.1%) of bromine or chlorine. Printed circuit board and substrate
laminates generally contain < 1500 ppm (0.15%) of total bromine and chlorine. Service parts after purchase may not be BFR/PVC-free.
External accessories, including power supplies, power cords, and peripherals as well as the following customer-configurable internal
components: ATT SIM card are not BFR/PVC-free.
*** Microsoft Windows is required for ENERGY STAR qualification.
QuickSpecs
HP EliteBook 8460p Notebook PC
HP EliteBook 8560p Notebook PC
Overview
DA - 13947 North America — Version 20 — August 3, 2012 Page 5

HP EliteBook 8560p Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Display	LED
Expansion slots	1 Express Card/54; 1 lettore di Smart Card; 1 SD/MMC
Infrared data port	No
HDD controller type	Unità a stato solido
Graphics card family	AMD
Intel segment tagging	Enterprise
Bundled software	Roxio My DVD 2010 SE Microsoft Office 2010 Norton Internet Security 2011
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Motherboard chipset	Intel® QM67 Express
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Display diagonal	15.6 \
Display resolution	- pixels
Audio system	SRS HD
Audio included	Audio ad alta definizione SRS, altoparlanti stereo integrati, uscita stereo cuffie/linea, ingresso microfono stereo, microfono integrato (array doppio microfono con webcam opzionale)
Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-2620M
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	27
Maximum number of PCI Express lanes	16
Pointing device	Touchpad + Pointing Stick
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
AC adapter power	65 W
Battery capacity	55 Wh
Number of battery cells	6
Sustainability certificates	ENERGY STAR
On-board graphics card ID	0x116
Discrete graphics card model	AMD Radeon HD 6470M
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz
Processor code	SR041
Processor ARK ID	52231
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Country of origin	China

Weight and Dimensions

Depth	250 mm
Width	374 mm
Height	34 mm
Weight	2730 g
