HP EliteBook 8560p Specification

Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.
Optional HP BB09 Ultra
Extended Life Notebook
Battery
Dimensions (H x W x L) 1.2 x 5.9 x 11.4 in (3x15x29cm)
Weight (max) 1.5lb, (.682kg)
Cells/Type Lithium-Ion
Energy Voltage 11.25V
Amp-hour capacity 8.85Ah
Watt-hour capacity 100Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 122° F(-10° to 50° C)
Non-operating -4° to 122° F (-20° to 50° C)
Battery Re-Charge Time System in OFF or Standby
Mode
3.5 to 5 hours
System ON 4 to 7 hours
Fuel Gauge LED Yes
Warranty 1 year
Optional Travel Battery
Available
NA
Optional HP ST09
Extended Life Notebook
Battery
Dimensions (H x W x L) 1.2 x 6.1 x 12 in (3x15.5x30.5cm)
Weight (max) 1.2lb, (.550kg)
Cells/Type Lithium-Ion Polymer
Energy Voltage 11.1V
Amp-hour capacity 6.6Ah
Watt-hour capacity 73Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 122° F(-10° to 50° C)
Non-operating -4° to 122° F (-20° to 50° C)
Battery Re-Charge Time System in OFF or Standby
Mode
3.5 to 5 hours
System ON 4 to 7 hours
Fuel Gauge LED Yes
Warranty 1 year
Optional Travel Battery
Available
NA
QuickSpecs
HP EliteBook 8460p Notebook PC
HP EliteBook 8560p Notebook PC
Technical Specifications
DA - 13947 North America — Version 20 — August 3, 2012 Page 21

HP EliteBook 8560p Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Display	LED
Expansion slots	1 Express Card/54; 1 lettore di Smart Card; 1 SD/MMC
Infrared data port	No
HDD controller type	Unità a stato solido
Graphics card family	AMD
Intel segment tagging	Enterprise
Bundled software	Roxio My DVD 2010 SE Microsoft Office 2010 Norton Internet Security 2011
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Motherboard chipset	Intel® QM67 Express
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Display diagonal	15.6 \
Display resolution	- pixels
Audio system	SRS HD
Audio included	Audio ad alta definizione SRS, altoparlanti stereo integrati, uscita stereo cuffie/linea, ingresso microfono stereo, microfono integrato (array doppio microfono con webcam opzionale)
Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-2620M
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	27
Maximum number of PCI Express lanes	16
Pointing device	Touchpad + Pointing Stick
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
AC adapter power	65 W
Battery capacity	55 Wh
Number of battery cells	6
Sustainability certificates	ENERGY STAR
On-board graphics card ID	0x116
Discrete graphics card model	AMD Radeon HD 6470M
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz
Processor code	SR041
Processor ARK ID	52231
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Country of origin	China

Weight and Dimensions

Depth	250 mm
Width	374 mm
Height	34 mm
Weight	2730 g
