HP EliteBook 8560p Specification

1.
2.
FAX Profile (FAX)
Basic Imaging Profile (BIP)
2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
indicates the profile is supported by Microsoft Windows XP SP2
indicates the profile is part of Windows Vista
Environmental Data Eco-Label Certifications This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
US Energy star
IT ECO declaration
EPEAT – Gold
System Configuration The configuration used for the Energy Consumption and Declared Noise
Emissions data for these models are based on a "Typically Configured
Notebook"
HP EliteBook 8460p Notebook PC
Energy Consumption 115 VAC 230 VAC 100 VAC
Normal Operation 11.57 W 12.11 W 11.45 W
Sleep (Energy Star low
power mode)
1.23 W 1.31 W 1.14 W
Off 0.56 W 0.62 W 0.51 W
Heat Dissipation * 115 VAC 230 VAC 100 VAC
Normal Operation 40 BTU/hr 41 BTU/hr 390 BTU/hr
Sleep 4 BTU/hr 4 BTU/hr 4 BTU/hr
Off 2 BTU/hr 2 BTU/hr 2 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
System Fan Off Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle 3.3 26.7
Fixed Disk
(random writes)
3.4 30.2
System fan is usually off except when charging the battery
Batteries This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
QuickSpecs
HP EliteBook 8460p Notebook PC
HP EliteBook 8560p Notebook PC
Technical Specifications
DA - 13947 North America — Version 20 — August 3, 2012 Page 41

HP EliteBook 8560p Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Display	LED
Expansion slots	1 Express Card/54; 1 lettore di Smart Card; 1 SD/MMC
Infrared data port	No
HDD controller type	Unità a stato solido
Graphics card family	AMD
Intel segment tagging	Enterprise
Bundled software	Roxio My DVD 2010 SE Microsoft Office 2010 Norton Internet Security 2011
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Motherboard chipset	Intel® QM67 Express
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Display diagonal	15.6 \
Display resolution	- pixels
Audio system	SRS HD
Audio included	Audio ad alta definizione SRS, altoparlanti stereo integrati, uscita stereo cuffie/linea, ingresso microfono stereo, microfono integrato (array doppio microfono con webcam opzionale)
Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-2620M
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	27
Maximum number of PCI Express lanes	16
Pointing device	Touchpad + Pointing Stick
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
AC adapter power	65 W
Battery capacity	55 Wh
Number of battery cells	6
Sustainability certificates	ENERGY STAR
On-board graphics card ID	0x116
Discrete graphics card model	AMD Radeon HD 6470M
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz
Processor code	SR041
Processor ARK ID	52231
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Country of origin	China

Weight and Dimensions

Depth	250 mm
Width	374 mm
Height	34 mm
Weight	2730 g
