Page #42 background imageLoading...
Page #42 background image
Cadmium greater than 10ppm by weight
The battery type and chemistry used in the product is:
CR2032 (coin cell), Li-ion
6-cell high capacity Lithium-Ion battery (optional 8 cell available)
Additional
information
This product is in compliance with the Restrictions of Hazardous Substances
(RoHS) directive – 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and Electronic
Equipment (WEEE) Directive – 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold
level, see:
www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per ISO
11469 and ISO1043.
This product contains 0% post consumer recycled plastic (by wt.)
This product is greater than 95.1% recycle-able when properly disposed of at
end of life.
Packaging Materials
External:
Corrugated Paper – 500 g
CANON bags-several layers – 5 g
Internal:
Polyethylene – 15 g
Molded pulp – 180 g
The Corrugated Paper packaging material is made from 80% recycled
content.
The CANON bags-several layers packaging material is made from 80%
recycled content.
The Polypropylene packaging material is made from 80% recycled
content.
The Molded Pulp packaging material is made from 80% recycled
content.
HP follows these guidelines to decrease the environmental impact of product
packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
QuickSpecs
HP EliteBook 8460p Notebook PC
HP EliteBook 8560p Notebook PC
Technical Specifications
DA - 13947 North America — Version 20 — August 3, 2012
Page 42

Table of Contents

Other manuals for HP EliteBook 8560p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8560p and is the answer not in the manual?

HP EliteBook 8560p Specifications

General IconGeneral
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1333 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory16 GB
HDD speed7200 RPM
HDD interfaceSATA II
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity500 GB
Compatible memory cardsMMC, SD
DisplayLED
Expansion slots1 Express Card/54; 1 lettore di Smart Card; 1 SD/MMC
Infrared data portNo
HDD controller typeUnità a stato solido
Graphics card familyAMD
Intel segment taggingEnterprise
Bundled softwareRoxio My DVD 2010 SE Microsoft Office 2010 Norton Internet Security 2011
Operating system installedWindows 7 Professional
Operating system architecture64-bit
Motherboard chipsetIntel® QM67 Express
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)10 - 90 %
Display diagonal15.6 \
Display resolution- pixels
Audio systemSRS HD
Audio includedAudio ad alta definizione SRS, altoparlanti stereo integrati, uscita stereo cuffie/linea, ingresso microfono stereo, microfono integrato (array doppio microfono con webcam opzionale)
Bus typeDMI
SteppingJ1
Tjunction100 °C
Processor cache4 MB
Processor cores2
Processor modeli7-2620M
System bus rate5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-2600 Mobile Series
Processor socketBGA 1023
Processor threads4
Processor codenameSandy Bridge
Processor frequency2.7 GHz
Processor cache typeSmart Cache
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency3.4 GHz
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)27
Maximum number of PCI Express lanes16
Pointing deviceTouchpad + Pointing Stick
Bluetooth version2.1+EDR
Cabling technology10/100/1000Base-T(X)
Networking featuresGigabit Ethernet
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity0
AC adapter power65 W
Battery capacity55 Wh
Number of battery cells6
Sustainability certificatesENERGY STAR
On-board graphics card ID0x116
Discrete graphics card modelAMD Radeon HD 6470M
On-board graphics card modelIntel® HD Graphics 3000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1300 MHz
Processor codeSR041
Processor ARK ID52231
Processor package size37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Country of originChina
Weight and Dimensions IconWeight and Dimensions
Depth250 mm
Width374 mm
Height34 mm
Weight2730 g
