d.
Remove the webcam/microphone module (4). The webcam/microphone module is available
using spare part numbers 699688-001 (with keyboard light for use only on HP EliteBook
8570p Notebook PC computer models) and 699687-001 (without keyboard light for use
only on HP ProBook 6570b Notebook PC computer models).
11. If it is necessary to replace the display panel:
NOTE: Substeps a through c apply to an HP EliteBook 8570p Notebook PC computer model.
See substeps d through f for display panel release procedures for an HP EliteBook 6570b
Notebook PC computer models.
a. Remove the two Phillips PM2.5×4.6 screws (1) that secure the top edge of the display panel
to the display enclosure.
b. Remove the four Phillips PM2.5×5.6 screws (2) that secure the display hinges and the bottom
edge of the display panel to the display enclosure.
