2. Remove the Phillips PM2.0 × 3.0 screw (1) that secures the solid-state drive to the system board.
3. Pull the drive (2) away from the socket to remove it.
To install the solid-state drive, reverse the removal procedures.
NOTE: Solid-state drives are designed with a notch to prevent incorrect insertion.
WWAN module
To remove the WWAN module, use this procedure and illustration.
Table
5-4 WWAN module descriptions and part numbers
Description Spare part number
Intel XMM 7360 LTE-Advanced (Cat 9) L70670-001
Qualcomm Snapdragon X55 LTE + 5G L83053-001
Component replacement procedures 39
