NOTE: After installing a new processor onto the system board, update the system ROM to ensure that the
latest version of the BIOS is being used on the computer. The latest system BIOS can be found on the Web at:
http://h18000.www1.hp.com/support/les.
Speaker
1. Prepare the computer for disassembly (Preparation for disassembly on page 19).
2. Remove the access panel (Access panel on page 20).
3. Disconnect the speaker wire from the system board connector labeled SPKR (1) and remove the wire
from the clip (2).
4. From the inside of the chassis, remove the silver Torx T15 screw (3) that secures the speaker to the
chassis.
5. Remove the speaker from the chassis (4).
To replace the speaker, reverse the removal procedures.
46 Chapter 4 Removal and replacement procedures – Microtower (MT) chassis
