Removing the computer access panel
To access internal components, you must remove the access panel.
1. Remove/disengage any security devices that prohibit opening the computer.
2. Remove all removable media, such as compact discs or USB ash drives, from the computer.
3. Turn o the computer properly through the operating system, and turn o any external devices.
4. Disconnect the power cord from the AC outlet and disconnect any external devices.
IMPORTANT: Regardless of the power-on state, voltage is always present on the system board as long
as the system is plugged into an active AC outlet. You must disconnect the power cord to avoid damage
to the internal components of the computer.
5. Pull up the access panel handle (1), and then slide the panel back (2) and lift it o the computer (3).
6 Chapter 2 Hardware upgrades
