Front panel components
Front panel components
1 USB Type-C port 5 Audio-out (headphone)/Audio-in (microphone)
combo jack
2 USB SuperSpeed port 6 Hard drive activity light
3 USB SuperSpeed port with HP Sleep and Charge 7 Power button
4 Audio-out (headphone) jack
NOTE: The USB SuperSpeed port with HP Sleep and Charge provides current to charge a device such as a smart phone. The charging
current is available whenever the power cord is connected to the system, even when the system is o.
The audio-out (headphone)/audio-in (microphone) combo jack supports headphones, line output devices, microphones, line input
devices, or CTIA style headsets.
2 Chapter 1 Product features
