HP EliteDesk 705 G4 Desktop Mini User Manual

Replacing the WLAN module
1. Remove/disengage any security devices that prohibit opening the computer.
2. Remove all removable media, such as a USB ash drive, from the computer.
3. Turn o the computer properly through the operating system, and turn o any external devices.
4. Disconnect the power cord from the AC outlet and disconnect any external devices.
IMPORTANT: Regardless of the power-on state, voltage is always present on the system board as long
as the system is plugged into an active AC outlet. To prevent damage to internal components, you must
disconnect the power cord from the power source before opening the computer.
5. If the computer is on a stand, remove the computer from the stand and lay the computer down.
6. Remove the computer access panel.
For instructions, see Removing the computer access panel on page 9.
7. To access the WLAN module, you must remove the hard drive cage or the graphics processor, depending
on your model.
For models with a hard drive:
a. Rotate the hard drive latch up (1) to disengage the hard drive from the cage. Then slide the drive
toward the rear of the chassis until it stops, and then lift the hard drive up and out of the cage (2).
Replacing the WLAN module 25

HP EliteDesk 705 G4 Desktop Mini Specifications

General

Power Supply	65 W external power adapter
Processor Options	AMD Ryzen™ 5 PRO 2400GE with Radeon™ Vega Graphics; AMD Ryzen™ 3 PRO 2200GE with Radeon™ Vega Graphics; AMD Athlon™ PRO 200GE with Radeon™ Vega Graphics
Memory	Up to 32 GB DDR4-2666 SDRAM
Storage Options	One M.2 2280 PCIe NVMe SSD
Graphics	AMD Radeon Vega Graphics
Ports	1x USB 3.1 Gen 1
Networking	Gigabit Ethernet
Dimensions	17.7 x 17.5 x 3.4 cm
Weight	1.26 kg
Operating System	Windows 10 Pro 64; Windows 10 Home 64; FreeDOS
Audio	Conexant CX20632 codec
