NOTE: To view information on the screen in portrait mode, you can install the HP Display

Assistant software included on the software and documentation media disc. The position of the

OSD menu can also be rotated to portrait mode. To rotate the OSD menu, access the OSD

menu by pressing the Menu button on the front panel, select OSD Control from the menu, then

select Rotate OSD.

Removing the Monitor Pedestal Base

You can remove the monitor panel from the pedestal base to install the panel on a wall, a swing arm,

or other mounting fixture.

CAUTION: Before beginning to disassemble the monitor, be sure the monitor is turned off and the

power and signal cables are disconnected. Also disconnect all USB cables connected to the monitor.

1. Disconnect and remove all cords and cables from the monitor.

2. Lay the monitor face down on a flat surface covered by a clean, dry cloth.

3. Pivot the base 45 degrees clockwise and remove the screw from the back of the monitor, then

pivot the base 45 degrees counter-clockwise and remove the other screw from the back of the

monitor.

4. Rotate the base of the monitor up (1) then pull it back (2) to unhinge the tabs on the monitor

stand from the slots in the monitor.

ENWW Removing the Monitor Pedestal Base 15

Questions and Answers:

Need help?

Do you have a question about the HP EliteDisplay S231d and is the answer not in the manual?

HP EliteDisplay S231d Specifications

General

3D	-
Pixel pitch	0.265 x 0.265 mm
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 60 Hz
Horizontal scan range	24 - 80 kHz
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509 mm
Display brightness (typical)	250 cd/m²
HDCP	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
HDMI ports quantity	0
USB Type-A downstream ports quantity	2
Product color	Black
Country of origin	China
Market positioning	Business
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power consumption (standby)	2.2 W
Power consumption (typical)	38 W
Sustainability certificates	ENERGY STAR
