The monitor automatically scans the video input connections for an active signal at power on, and if

using the monitor's default settings, will display video on the first input detected with an active signal.

If two or more inputs are active, the default input and auto-switch input settings will determine the

priority of the input signal being displayed. To switch between USB, DisplayPort and VGA inputs,

press the Input Control button on the monitor's front panel.

Connecting an HP Notebook Computer and Installing

Drivers

To use the monitor with an HP notebook computer, connect the USB cable between the notebook

and monitor and install the USB and LAN drivers. The video signal is sent over the USB cable. The

USB cable also enables all of the port replicator functions.

CAUTION: Do not install more than one set of USB graphics drivers. Doing so can cause software

incompatibility issues between drivers and result in no picture on one of the displays.

You can install the drivers from the media disc included with the monitor before connecting the

notebook to the monitor or you can install the drivers from the monitor's internal flash drive after

connecting the notebook to the monitor.

To install the drivers from the monitor's internal flash drive:

1. Turn on power to the monitor and the HP notebook computer.

2. Connect one end of the provided USB cable to a USB connector on the notebook computer, and

the other end to the upstream USB connector on the monitor.

NOTE: For optimal performance, connect the USB cable to a SuperSpeed USB or USB 3.0

port on the notebook. These ports are color-coded in blue or with an SS-USB icon. The monitor

will also function when connected to a USB 2.0 port but will run at lower overall data rates.

3. After the USB cable is connected, an AutoPlay window will pop up on the notebook's screen. In

the AutoPlay window, click on Open folder to view files.

NOTE: If the AutoPlay window does not pop up, open Microsoft Windows Explorer, navigate to

and select the HP S231d drive, then proceed to the next step.

4. Double-click the SETUP file.

ENWW Connecting an HP Notebook Computer and Installing Drivers 9

Questions and Answers:

Need help?

Do you have a question about the HP EliteDisplay S231d and is the answer not in the manual?

HP EliteDisplay S231d Specifications

General

3D	-
Pixel pitch	0.265 x 0.265 mm
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 60 Hz
Horizontal scan range	24 - 80 kHz
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509 mm
Display brightness (typical)	250 cd/m²
HDCP	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
HDMI ports quantity	0
USB Type-A downstream ports quantity	2
Product color	Black
Country of origin	China
Market positioning	Business
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power consumption (standby)	2.2 W
Power consumption (typical)	38 W
Sustainability certificates	ENERGY STAR
